四端口光纤环形器 1310nm 1550nm |
|
|
|
|
|
|
|
| 四端口光纤环形器，光只能沿一个方向传播。信号若从端口1输入，则从端口2输出；而信号从端口2输入，则将从端口3输出，从端口3输入，则从端口4输出。是不可逆光学器件。由于其隔离性高，插入损耗小，光纤环行器广泛用在先进通信系统中，例如分插复用器，双向泵浦系统和色散补偿装置。高功率光纤环形器是在此基础上的研发改进型产品，飞博特可定制的波长非常齐全并可承受大功率，有（850、980、1053、1064、1310、1550、1650nm等等波长，部分波长功率可满足5~10W功率。 |
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
产品特点 |
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
♦ 高隔离度 |
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
♦ 低附加损耗 |
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
♦ 承受高功率 |
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
应用 |
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
♦光纤传感 |
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
♦高级光纤通信 |
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
♦实验室研究 |
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
| 产品规格 |
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
| 指标名称 |
|
|
|
单位 |
标准值 |
极限值 |
|
|
|
| 中心波长 |
|
|
|
nm |
1310、1450、1550、1580、1610、1650 |
|
|
|
|
|
|
| 带宽范围 |
|
|
|
nm |
±20 |
|
|
|
|
| 端口及工作方式 |
|
|
|
|
|
4端口， (Port 1→2, 2→3，3→4) |
|
|
|
|
|
|
| 插入损耗（Type） |
dB |
0.8 |
Max. |
|
|
|
| 插入损耗（@23℃） |
dB |
1.0 |
Max. |
|
|
|
| 峰值隔离度（Type） |
dB |
50 |
|
|
|
|
| 隔离度（@23℃） |
dB |
40 |
Min. |
|
|
|
| 串扰 |
|
|
|
|
dB |
50 |
Min. |
|
|
|
| 偏振相关损耗 |
|
dB |
0.2 |
Max. |
|
|
|
| 偏振模色散 |
|
|
ps |
0.1 |
Max. |
|
|
|
| 方向性 |
|
|
|
dB |
50 |
Min. |
|
|
|
| 回波损耗 |
|
|
|
dB |
50 |
Min. |
|
|
|
| 承受功率 |
|
|
|
mW |
500 |
|
|
|
|
|
|
| 拉伸载荷 |
|
|
|
N |
5 |
Max. |
|
|
|
| 光纤类型 |
|
|
|
|
Corning SMF-28e Fiber or customized |
|
|
|
|
| 操作温度 |
|
|
|
℃ |
-5 to +50 |
|
|
|
|
|
|
| 储藏温度 |
|
|
|
℃ |
-20 to +85 |
|
|
|
|
|
| 封装尺寸 |
|
|
|
mm |
5.5*64 |
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
| 备注 |
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
| * 以上为不含接头测试数据。 |
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
| 订购信息 |
|
|
|
|
| PICIR-AAAA-BB-C-DD-EE |
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
| 波长 AAAA |
|
端口 B |
|
|
|
|
|
套管类型C |
|
|
|
|
|
|
尾纤长度 DD |
接头类型 EE |
|
|
|
| 1550 - 1550nm |
|
4 - 4端口 |
|
|
|
|
B - 250um Bare fiber |
|
|
|
|
05 - 0.5m |
|
|
|
NE - None |
|
|
|
|
|
|
| SSSS - Specify |
|
|
|
|
|
|
|
|
L - 900um Loose tube |
|
|
|
08 - 0.8m |
|
|
|
|
|
FA - FC/APC |
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
10 - 1.0m |
|
|
|
|
|
FP - FC/PC |
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
15 - 1.5m |
|
|
|
|
|
SA - SC/APC |
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
SS - Specify |
|
|
|
|
|
LP - LC/PC |
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
SS - Specify |
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
